Customizable NTC Temperature Sensor With Wide Operating Temperature Range And Volt For Temperature Instruments
| Accuracy: | ±0.5℃ | Thermal Time Constant: | ≤ 10s |
| Application: | Air Conditioner Temperation Sensor | Lead Wire: | PVC , XLPE, , Fibreglass Silica Gel... |
| Size: | 6mm*6mm | Temperature Dviation: | 0℃～+85℃ ±0.3℃ |
| Highlight: | Customizable NTC Temperature Sensor, NTC Temperature Sensor 6mm, Air Conditioner NTC Temperature Sensor | ||
Product Description
Customizable NTC Temperature Sensor With Wide Operating Temperature Range And Volt For Temperature Instruments
Features
● The material and size of tube can becustomized according to client's requirement size deviation is small,esayto install.
● Operation temperature range:-50~150℃ or -40-250℃
● Thermal time constant (Stainless steel 4S,Nickel plating copper 3S,Copper 2S)
● Water proof Grade:IP66
● Voltage ressistace test with AC1800V 30S
● The wire and terminal can becustomized according to client's requrment
Applications
Suitable for heating mattresses,electric blankets,heating mats,batteries, smart small appliances,new energy vehicles,batteries,and indoor
temperature measurement and control.
| Temperature sensor | Nominal resistance value | B value | Rated power | Dissipation coefficient | Thermal time constant | Operating temperature |
| R25(Ω) | 25/50℃ | (mw) | (mwC) | (S) | (℃) | |
5K3470 5K3950 10K3435 10K3950 15K3950 20K3950 50K3950 100k395 【Customizable】 | 5K 10K 15K 20K 30K 50K 100K 200K 【Customizable】 | 3435 3470 3950 4100 4200【Customizable】 | ≤50 | ≥2.0 Still in the air | ≤15 Still in the air | -40~ 200℃ |
Product customization instructions
(1) resistance value of the product (25 ° C resistance nominal resistance value, or other)
(2) product accuracy (1% ~ 5%)
(3) product b-value coefficient
(4) wire type and length (color, length, temperature resistance requirements)
(5) wire tail specifications (dip tin, Socket Plug, special specifications)
(6) probe specifications and materials (copper-plated nickel, copper, stainless steel, ABS rubber shell)
(7) use temperature range
